220V/110V Micro Spot Welding Machine Battery Spot Welder Dual Pulse

Description This kind of spot welders are specially designed to meet the needs for the production of high-grade batteries (nickel-cadmium, nickel-hydrogen, lithium batteries). Single-chip microprocessor control is adopted to ensure higher stability and reliabilities in performance. Also a current loop was formed at the same time. These will not hurt internal structure of work piece. Absolutely an ideal choice for battery welding, such as laptop/mobile phone battery, lithium battery etc Parameters 1. Input power supply: AC220V/110V available 2. Max outpuot power: 3KVA 3. Welding current: 00-99% 4. Electrode stroke: 20mm 5. The control mode: double pulse 6. Net weight: 5KG 7. Dimensions: 260*160*200mm Operation A. Height adjustment of Welding needles : loosing the height adjustment screw with a wrench. Then adjust or replace the length of needles exposed below the electrode(usually, it is about 15mm. It is easy to deform if it is too long) finally, tightening screws. B. Width adjustment of Electrode (needles) : loosing the width adjusting screw with a wrench, then adjust two electrodes so that two needles to appropriate distance. Last, tightening the screws. C. Test: test whether there is coke on the needles or not., if so. you need to clear it with a file or abrasive paper. then using the right foot press pedals . When its head drop, stare the welding needles until the needle is on the welding point. D. Power: put plug into a 220V power socket, and turn on the power switch, indicator flashing, the welder is work. If working indicator does not shine or shine without flashing, turning off the power then turn on again. E. In order to ensure good quality of welding, you should often adjust needles and keep it in a good condition.

• Efficient: This micro spot welding machine is an efficient tool for welding battery packs, as well as other small metal parts. It utilizes dual pulse technology to ensure a strong and reliable weld each time.
• Precise: The machine is equipped with an LCD screen and control panel that allow you to adjust the weld time and current with precision, ensuring accurate and consistent welds.
• Compact: The compact design of this spot welder makes it perfect for small workspaces or on-the-go projects. Its light weight and portability make it easy to transport and store when not in use.
• Safe: The machine features built-in safety features, such as overcurrent protection and overheating prevention, to ensure safe use and avoid damage to the equipment or materials.
• Versatile: This spot welder is perfect for a variety of metal welding projects, such as welding nickel strips, welding aluminum wire, and welding thin steel plates. The dual pulse technology allows for precise and reliable welding of different types of metals.
