4-Ch. Vehicle Audio Bass Amplifier - 1000 Watts High-Powered Mono Bass Amplifier w/Subsonic Filter & Low Pass Filter Stable at 2 ohm, LED Indicators, Sound Specialization, Red
Product details
| Management number | 208592032 | Release Date | 2026/03/22 | List Price | $36.00 | Model Number | 208592032 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
* Class D vehicle audio amplifier * Total Power 14.4 @ 1 Ohm: 3900 WRMS * Total Power 14.4 @ 2 Ohms: 2900 WRMS * Total Power 12.6 @ 1 Ohm: 3000 WRMS * Total Power 12.6 @ 2 Ohms: 2300 WRMS * Efficiency @ 2 Ohms: 78% * Efficiency @ 1 Ohm: 71% * Input Voltage: 9 to 15V * Input Impedance: 100K Ohms * THD+Noise: less than 1% * Input Sensitivity: 110mV to 4V * SNR: 80dB * Frequency Response: 20 to 20KHz (-3dBs) * HPF (Subsonic): 20 to 80Hz @ 12dB/octave Linkwitz-Riley * LPF (Crossover): 80 to 20kHz @ 12dB/octave Linkwitz-Riley * Recommended Fuse: 150 A * Current at Rest: 1.5 A * Average Current Draw (Sinusoidal): 360 A * Average Current Draw (Music): 180 A * Power Wire Gauge (min. Recommended): 21mm / 4 AWG * Speaker Wire Gauge (min. Recommended): 2 x 4mm / 2 x 11 AWG * Weight (Lb): 7.6, Height (in): 2.2, Width (in): 8.4, Depth (in): 9.7
- POWER SUPPLY: Class D vehicle audio amplifier, Total Power 14.4 @ 1 Ohm: 3900 WRMS, Total Power 14.4 @ 2 Ohms: 2900 WRMS, Total Power 12.6 @ 1 Ohm: 3000 WRMS, Total Power 12.6 @ 2 Ohms: 2300 WRMS, Efficiency @ 2 Ohms: 78%, Efficiency @ 1 Ohm: 71%
- MONO BASS AMPLIFIER INDICATORS: Blue LED: source and powered amplifier indicator, Red LED: output distortion (clipping), shorting and thermal protection indicator, Yellow LED: below specified voltage indicator (flashing)
- POWER OUTPUT AND IMPEDANCE: Input Voltage: 9 to 15V, Input Impedance: 100K Ohms, THD + Noise: less than 1%, Input Sensitivity: 110mV to 4V, Signal to Noise Ratio: 80dB
- SOUND SPECIALIZATION: This high-powered Power Amplifier is cutting edge technology at its finest. RCA connectors ensure a secure connection between amplifier and speakers that allow distortion-free sound
- OTHER TECHNICAL SPECS: Recommended Fuse: 150A, Current at Rest: 1.5A, Ave. Current Draw (Sinusoidal): 360 A, Ave. Current Draw (Music): 180 A, Power Wire Gauge: 21mm/4 AWG, Speaker Wire Gauge: 2 x 4mm/2 x 11 AWG, Size: 9.7'' x 8.4'' x 2.2'' -inches
| Brand | Banda Audioparts |
|---|---|
| Voltage | 15 Volts (DC) |
| Item Weight | 1 pounds |
| Manufacturer | Banda |
| Output Power | 3900 Watts |
| Mounting Type | Surface Mount |
| Supply Current | 1.5 Amps |
| Item model number | BEAT3000.1GREEN |
| Specification Met | CE |
| Number of Channels | 1 |
| Package Dimensions | 10.04 x 9.65 x 2.36 inches |
| Maximum Supply Voltage | 15 Volts (DC) |
| Minimum Supply Voltage | 9 Volts |
