HGM4100LT Single Unit Automation+ Remote Signal Start/Stopsingle Unit Automation+ Remote Signal Start/Stop

HGM4100LT Power Station Automatic Controller is designed especially for adapting extremely low/high temperature (-40~+70)℃, which integrates digitization, intelligentization and network technology, and are used for single genset automation and monitoring control system, in order to achieve automatic start/stop, data measurement, alarm protection etc. functions. It applies LCD display, optional interface operation with eight languages (Chinese, English, Spanish, Russian, Turkish, French, Portugal, and Polish). It is simple to operate and reliable to work. HGM4100LT Power Station Automatic Controller employs micro-processor technology, which makes these functions come true, including precise parameter measuring, fixed value adjustment, time setting and integer limit value adjusting etc. All parameters can be configured from the front panel. They can also be adjusted and monitored through programmable interfaces (USB or RS485 interface) via PC. Because of the characteristics of compact structure, simple wiring connection and high reliability, it can be widely used in all types of automatic genset control system.

• HGM4100LT: it is used for single unit automation and genset auto Start/Stop control by remote start signals.
• LCD display with backlight, 132x64 size, and eight language display (Chinese, English, Spanish, Russian, Turkish, French, Portugal, and Polish), push-button operation;
• Hard acrylic screen material with great wear-resisting and scratch-resisting performance, which are used to protect the screen;
• Silicone panel and pushbuttons which can better adapt extreme temperature environment;
• RS485 communication interface, which enables “Three remote functions” (remote control, remote measuring and remote communication) by MODBUS protocol;
